    FT20 Thermal Camera 256*192 High Resolution Thermal Imaging Temperature Measure Device with SDK for Android Device

    Ask Lasest Price
    Brand Name : SCANMAX
    Model Number : FT20
    Certification : CE, RoHS,CC
    Price : Negotiation
    Payment Terms : Western Union, T/T, Paypal
    Supply Ability : 1000 PCS/ week
    Delivery Time : Within 5 working days after receiving the balance
    • Product Details
    • Company Profile

    FT20 Thermal Camera 256*192 High Resolution Thermal Imaging Temperature Measure Device with SDK for Android Device

    Product Description
    The temperature measuring thermal imaging module is developed based on wafer chip scale packaging uncooled vanadium oxide infrared detector, fit for working with various intelligent platform. It boasts the features of high performance, low power consumption, small size and easy for development and integration. It meets the secondary development requirement of various infrared temperature measuring applications.


    Product Features
    *Small size, easy integrated,size :91mm (L)*48mm(W)*25mm(H);
    *USB interface, easy to connect;
    *Low power consumption;
    *High image quality
    *Accurate temperature measurement;
    *Standard data interface, supporting secondary development, easy to integrate, and supporting access to various intelligent processing platforms.


    Product Parameters:

    ModelFT20
    Resolution256×192
    Cellspacing12μm
    Angle of view25.5°×19.2°
    Image frame rate25Hz/15Hz
    NETD≤60mK@f#1.0
    Operating temperature-15℃~+60℃
    Supply voltage3.8V-5.5V DC
    Power consumption<200mW*
    Weight<18g
    Size / mm20*20*21
    Data interfaceControl interface/USB
    Control interfaceSPI/I2C/USB
    Image enhancementMulti-gear detail enhancement
    Picture correctionShutter correction
    SwatchesWhite Hot/Black Hot/Multiple Pseudo Color Options
    Temp measurement range0 ℃ ~ + 60 ℃
    Temp measurement accuracy± 0.5 ℃ / ± 5% of range
    Temp correctionManual / Auto
    Temperature data outputReal-time parallel output
    Temp measurement statisticsSupport maximum / minimum statistics, Temperature analysis
