    WIFI Face Recognition 8 Inch Body Temperature Check Machine

    Ask Lasest Price
    Brand Name : SCANMAX
    Model Number : F2-FHS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
    • Product Details
    • Company Profile

    WIFI Face Recognition 8 Inch Body Temperature Check Machine

    F2-FHS Face Recognition Body Temperature Integrated Machine
    (with QR code reader,IC Card Reader)

    Face Recognition Body Temperature Integrated Machine Application

    It is suitable for thousands of people's office areas, hotels, access gates, office buildings, schools, shopping malls, shops, communities, public services and management projects that require face access control.

    Face Recognition Body Temperature Integrated Machine Details

    Identification height 1. 2-2.2 m
    Identification distance 0.5- 1.5m (temperature test distance)
    Recognition technology: Near-infrared live detection, embedded visible light face recognition, adapt to most indoor and outdoor environments, can quickly recognize on the move
    5°C Accurate temperature detection: 2-3 seconds per person-time temperature detection accuracy
    Status display Name broadcast display, custom information broadcast display

    Face Recognition Body Temperature Integrated Machine Specification


    Face Recognition Temperature Measure all-in-one Machine
    Product modelF2-FHS


    Characteristics

    Main functionFace recognition temperature measurement
    Use environmenIndoor , semi-outdoor
    ColorSilver









    Camera

    TypeRGBInfrared
    Resolution2 million pixels2 million pixels
    ApertureF2.8F2.8
    Focal length3.18mm3.18mm

    Software
    Dynamic


    automatic


    automatic

    Vertical wide
    angle


    84°


    84°

    Horizontal wide
    angle


    54°


    54°

    Infrared
    supplement light

    Support

    White
    supplement light

    Support


    Core parameters

    AndroidAndroid7.1
    CPUQuad-core, 1.8GHz
    storage capacityRAM 2G ROM 8G






    Human-comput er interaction


    Monitor

    8 inches, full viewing angle, 170 ° IPS LCD screen, resolution
    800 * 1280

    Touch screensupport

    Face sensing
    module

    support

    Face temperature measurement
    module


    support,Serial / I2C interface

    Card readerSupport, Optional

    Communication
    method

    Ethernet10/100 Ethernet
    WIFIComply with IEEE802.11b / g / n standard (2.4G)


    Identification Method

    FaceSupport
    IC cardSupport, optional


    Input output interface

    RJ45 interfaceSupport 10/100 Mbps

    Power supply
    interface


    DC12V-2A

    PowerAdapterDC12V-2A



    Environmental requirements

    Operating
    temperature

    -20℃~60℃

    Working
    humidity


    20%~90% (non-condensing)

    Static protection
    level


    IEC61000-4-2, LEVEL3

    External Interface Definition
    TypeInterfaceExplanation
    USBUSB 2.0Support
    Ethernet portRJ4510/100 Ethernet



    Relay


    NC COM NO

    Relay normal off/Common/normal on.Usually,door lock supply is positively connected to the COM port,and then according to the door lock type,relay power negatively connected NO port or NC
    port. Note: Maximum load of relay contact is 2A


    Gate sensor

    IN
    GND


    Check door open/close status, input

    Exit
    button

    PUSH1
    GND


    Press the button,door opening control signal,input


    Serial

    RX
    TX


    RS232


    Output power

    5V
    GND


    Support device external output 5V


    Wiegand

    WG_D1 WG_D0
    GND


    Wiegand output interface, support 26bit / 34bit protocol


    Input power

    GND
    12V+

    Power input:12V DC






    Temperature measurement module

    Operating temperature


    0℃ ~ +55℃

    Storage temperature


    -20℃ ~ +65℃

    Power consumption


    < 0.3w





    Basic Parameters


    Pixel


    32*32 Real-time temperature output

    Measurement accuracy


    I + 0.5℃

    Measuring distance


    0.3 ~ 1.0m


    WIFI


    2.4G 802.11b/g/n


    Bluetooth


    BluetooH4.0




    Face Recognition Body Temperature Integrated Machine Details
