Real Time Smart 2D Barcode Scanner RD008 Door Access Control Lock

    Buy cheap Real Time Smart 2D Barcode Scanner RD008 Door Access Control Lock from wholesalers

    Buy cheap Real Time Smart 2D Barcode Scanner RD008 Door Access Control Lock from wholesalers
    • Buy cheap Real Time Smart 2D Barcode Scanner RD008 Door Access Control Lock from wholesalers
    • Buy cheap Real Time Smart 2D Barcode Scanner RD008 Door Access Control Lock from wholesalers
    • Buy cheap Real Time Smart 2D Barcode Scanner RD008 Door Access Control Lock from wholesalers
    • Buy cheap Real Time Smart 2D Barcode Scanner RD008 Door Access Control Lock from wholesalers

    Real Time Smart 2D Barcode Scanner RD008 Door Access Control Lock

    Ask Lasest Price
    Brand Name : Rakinda
    Model Number : RD008
    Certification : CE FCC ROHS
    Price : $200~170USD/pcs
    Payment Terms : L/C, T/T, Western Union,PayPal
    Supply Ability : 1000pcs per month
    Delivery Time : 3~7 working days
    • Product Details
    • Company Profile

    Real Time Smart 2D Barcode Scanner RD008 Door Access Control Lock

    Real Time Smart 2D Barcode Scanner RD008 Door Access Control Lock


    2D Barcode scanner RD008 Door Access Control System Machine Intelligent Smart Door Lock


    Product Features:

    1. Embedded multi-tasking real-time operating system, the system can be fully started in 3 seconds.

    2. Single door network access control + QR code scanning head +IC card reader triple product. Make the on-site installation and maintenance simple and cost-effective.

    3. The product comes with a voice amplifier and speaker. The voice for common entry and exit events can be set. The network can control nearly 150 voices and can customize the voice.

    4. Encrypted QR code that complies with the agreed rules can be opened / opened directly when not connected to the Internet.
    The agreed rules mainly include:
    (1) the start time and end time of the two-dimensional code valid;
    (2 )the number of times the two-dimensional code is valid and exceeds the number of uses, the two-dimensional code can no longer be used;
    (3) equipment MAC matching or project number building number Match, a QR code can contain one or more device numbers, which can be legally valid on multiple devices;
    (4)The encryption key of the QR code can be modified without leaving any backdoors or loopholes to ensure the security of the QR code.


    RD008 Round 2D IC Card Access Control Machine Product Specifications:

    RD008 Round 2D IC Card Access Control Machine
    QR Code Scanning Component Parameters
    Image Sensor752X480 CMOS
    Light SourceWhite/blue LED
    Symbologies2D: PDF417, QR CODE, DATA MATRIX,Support Mobile Phone Mirror Recognition and Paper 2D Code Recognition
    1D: CODE 128, UCC/EAN-128, AIM-128, EAN-8 etc.
    Reading Distance10mm-55mm
    Scan Angle360° Full Angle
    Display Components
    Screen1.8 ”TFT true color screen
    Resolution128 * 160
    Display Area28mmX35mm
    Input and Output Parameters
    Power Input9-18VDC
    Working Current< 600mA
    Can read like ISO14443Aor ISO14443B Card Serial NumberSuch as Second-generation ID card, FM1208 CPU Card, M1 Card (Mifare S50, Mifare S70 IC card), SRIX4K, etc.
    Barcode or 2D Code InputWiegand 26/34 output, output IC card number (common read head function) and associated card number output in compliance with QR code reservation rules
    Communication InterfaceRJ45 10/100M TCP/IP, Extensible Wireless WIFI, Bluetooth
    Communication ProtocolSupport TCP / UDP / HTTP
    Voice outputcomes with voice, amplifier and speaker output, nearly 150 kinds of voice output, customizable voice
    Device Input12V DC power input, 1 door magnetic input, 1 door button input, 1 alarm input
    Equipment output1 channel 3A relay output, 1 channel unlock, 1 channel expansion can control door opener, light, water valve, etc.
    Wiegand outputWiegand 26/34 output
    Dimensions
    Installation size110mm * 25-34.62mm (L*H), Compatible with standard 86 box

    Company Profile

    Rakinda Technologies Co.,Ltd (The predecessor is Longview Tech Enterprise Co., Limited ) has been established since 2000, which has 6 branches in total, which are in Guangzhou, Shenzhen, Xiamen, Suzhou, Chengdu, Beijing and HongKong. "Rakinda" and "SCANMAX" are our two independent brands. Rakinda is also a leading worldwide Internet of Things solution provider, which is specialized in 1D/2D barcode identification technology (Embedded/Fixed Mount/Handheld/Desktop Barcode Scanner, Android PDA, Mobile POS, etc.) , radio frequency identification (UHF) technology and face recognition technology almost 20 years . We are oriented by customer demands , focus on development and innovation of intelligent systems and strive to provide most competitive IoT application solutions and services. Promoting people's lifestyle to be more intelligent is our infinite pursuit.
